Meet UN100L
Specification
FAQ

Intel 12 Gen Alder-Lake N Architecture Processors

Equipped with 4/8 efficient cores.

N100/i3-N305

On Board 16GB

New Generation LPDDR5 Memory

Supports M.2 SATA SSD, 2.5 inch Hard Drive and TF Card

Easy to use, ultra-low power consumption

Quiet and power-saving. Energy-saving and environmentally friendly

Rich interface, easy to connect

HDMI+DP+USB-C

Supports three-screen display and one cable to connect all your devices

Support AV1 video decoding

Supports 4K60Hz HD output

Compact size, does not take up space

Keeps your desktop tidy

Supports VESA mounts

Can be placed flat or wall-mounted

Package Content

MINISFORUM UN100L

UN100 Processor

Intel® N100 Processor, 4 Cores/4 Threads
(6M Cache, up to 3.4 GHz)

Graphics

Intel® UHD Graphics

Memory

LPDDR5 Single Channel (OnBoard, 4800Mhz, up to 16GB)

Storage

M.2 2280 PCIe3.0 SSD ×1(PCIe 3.0 ×1 )

Storage Expansion

TF Card Slot ×1
UFS2.1(128G/256G Optional)
2.5 inch SATA3.0 HDD Slot ×1

Wireless Connectivity

Onboard Intel® Wireless-AC 9560 (Wi-Fi 5，BlueTooth 5.1)

Video Output

HDMI ×1, DisplayPort ×1, USB-C ×1

Audio Output

HDMI ×1, DisplayPort ×1, Audio Jack ×1

Ports & Buttons

RJ45 1000M Ethernet Port×1
USB2.0 Type-A Port ×2(In Back)
USB3.2 Gen2 Type-A Port ×2(In Front)
USB3.2 Gen2 Type-C ×1(Alt Data DP and PD)
HDMI ×1
DisplayPort ×1
DMIC ×1
Audio Jack ×1
Clear CMOS ×1

Power

DC 12V (adapter included)

System

Windows 11

1. Brand of SSD and RAM in the UN100L
We purchase essential hardware from different brands based on the same technical specifications, including SSDs, Wi-Fi cards, RAM, HDDs, power supplies, etc. Due to the limited resources and brands of RAM and SSD, we choose Samsung, Kingston, Crucial, Adata, Phison, etc. as our RAM and SSD suppliers.

Each piece of hardware has passed a strict quality inspection and met the factory's standards before it is delivered to MINISFORUM. In addition, there is no difference in the warranty policies of these hardware suppliers.

The hardware brands may vary from batch to batch. Please rest assured that they all meet MINISFORUM's standards and are all covered by the warranty.

2. Do you have a warranty on the UN100L?
All products purchased on MINISFORUM's official store are covered by our 2-year warranty. Learn more about our warranty policy.

3. Where do you ship to?
We offer free shipping for the majority of the world.
Available countries and regions:
United States, Saudi Arabia, Canada, Singapore, Australia, Japan, United Arab Emirates, South Korea, Malaysia, New Zealand, Hong Kong, Macau.

Learn more about our shipping policy.

For customers in Europe, please place your order in our branch stores https://store.minisforum.de/ and https://store.minisforum.uk/.

4. What's the maximum resolution? How many monitors can be connected at the same time?
Up to three monitors can be connected at the same time with a maximum resolution of 4K.

5. Can I use the USB-C port to power up the UN100L?
The USB-C port on the UN100/UN305 can be used as a power supply port.

6. What's the spec of Wi-Fi and Bluetooth of UN100L?
Wi-Fi 5
Bluetooth 4.2

7. Does the UN100L have pre-installed Windows?
Except for the barebones version, all versions come with Windows 11 pre-installed. The barebones version does not include RAM and SSD; therefore, it does not have pre-installed Windows 11.

8. How do I install Windows OS for the barebones version?
Please click the link to our support page below to download Windows 11.
Note: MINISFORUM does not offer keys for the Windows OS.
https://www.minisforum.com/front/support
