Intel 12 Gen Alder-Lake N Architecture Processors
Equipped with 4/8 efficient cores.
N100/i3-N305
🚚 Free Worldwide Shipping on All Orders!Shop Now
\n
\n\n
\nIntel 12 Gen Alder-Lake N Architecture Processors
\nEquipped with 4/8 efficient cores.
\nN100/i3-N305
\n\n
\n\n
\nOn Board 16GB
\nNew Generation LPDDR5 Memory
\nSupports M.2 SATA SSD, 2.5 inch Hard Drive and TF Card
\n\n
\n\n
\nEasy to use, ultra-low power consumption
\nQuiet and power-saving. Energy-saving and environmentally friendly
\n\n
\n\n\n
\n\n
\n\n![](\"https://i.shgcdn.com/82c757ea-bf33-4cc4-9d50-a0f78d775cf4/-/format/auto/-/preview/3000x3000/-/quality/lighter/\")
\n
\n\n
\n\n
\nRich interface, easy to connect
\nHDMI+DP+USB-C
\nSupports three-screen display and one cable to connect all your devices
\n\n
\n\n
\nSupport AV1 video decoding
\n\n
\n\n\n
\n\n
\n\n![](\"https://i.shgcdn.com/1081ade6-a360-44a2-8cbc-e6bd65431e65/-/format/auto/-/preview/3000x3000/-/quality/lighter/\")
\n
\n\n
\n\n
\nSupports 4K60Hz HD output
\n\n
\n\n\n
\n\n
\n\n![](\"https://i.shgcdn.com/c931e4cf-66eb-487f-bd6a-e4cb45a6fc40/-/format/auto/-/preview/3000x3000/-/quality/lighter/\")
\n
\n\n
\n\n
\nCompact size, does not take up space
\nKeeps your desktop tidy
\n\n
\n\n\n
\n\n
\n\n![](\"https://i.shgcdn.com/c7a551ec-69a5-4c0e-99b3-be65f31567d0/-/format/auto/-/preview/3000x3000/-/quality/lighter/\")
\n
\n\n
\n\n
\nSupports VESA mounts
\nCan be placed flat or wall-mounted
\n\n
\n\n\n
\n\n
\n\n![](\"https://i.shgcdn.com/3d82ee1f-56d9-4f44-bd92-b9f232e3fea6/-/format/auto/-/preview/3000x3000/-/quality/lighter/\")
\n
\n\n
\n\n\n\n\n\n
\nPackage Content
\n\n
\n\n
\n\n\n
\n\n
\n\n
\n\n
\nMINISFORUM UN100L
\n\n
\n\n\n
\n\n
\n\n
\n\n
\n\n
\n\n
\n\n
\nUN100 Processor
\n\n
\n\n
\n\n
\nIntel® N100 Processor, 4 Cores/4 Threads
(6M Cache, up to 3.4 GHz)
\n
\n\n
\n\n
\n\n
\n\n
\nGraphics
\n\n
\n\n
\n\n
\nIntel® UHD Graphics
\n\n
\n\n
\n\n
\n\n
\n\n
\nMemory
\n\n
\n\n
\n\n
\nLPDDR5 Single Channel (OnBoard, 4800Mhz, up to 16GB)
\n\n
\n\n
\n\n
\n\n
\n\n
\nStorage
\n\n
\n\n
\n\n
\nM.2 2280 PCIe3.0 SSD ×1(PCIe 3.0 ×1 )
\n\n
\n\n
\n\n
\n\n
\n\n
\nStorage Expansion
\n\n
\n\n
\n\n
\nTF Card Slot ×1
UFS2.1(128G/256G Optional)
2.5 inch SATA3.0 HDD Slot ×1
\n
\n\n
\n\n
\n\n
\n\n
\nWireless Connectivity
\n\n
\n\n
\n\n
\nOnboard Intel® Wireless-AC 9560 (Wi-Fi 5，BlueTooth 5.1)
\n\n
\n\n
\n\n
\n\n
\n\n
\nVideo Output
\n\n
\n\n
\n\n
\nHDMI ×1, DisplayPort ×1, USB-C ×1
\n\n
\n\n
\n\n
\n\n
\n\n
\nAudio Output
\n\n
\n\n
\n\n
\nHDMI ×1, DisplayPort ×1, Audio Jack ×1
\n\n
\n\n
\n\n
\n\n
\n\n
\nPorts & Buttons
\n\n
\n\n
\n\n
\nRJ45 1000M Ethernet Port×1
USB2.0 Type-A Port ×2(In Back)
USB3.2 Gen2 Type-A Port ×2(In Front)
USB3.2 Gen2 Type-C ×1(Alt Data DP and PD)
HDMI ×1
DisplayPort ×1
DMIC ×1
Audio Jack ×1
Clear CMOS ×1
\n
\n\n
\n\n
\n\n
\n\n
\nPower
\n\n
\n\n
\n\n
\nDC 12V (adapter included)
\n\n
\n\n
\n\n
\n\n
\n\n
\nSystem
\n\n
\n\n
\n\n
\nWindows 11
\n\n
\n\n\n\n\n","image":["https://img.miniforumhub.shop/images/product/minisforum-un100l-1.jpg","https://img.miniforumhub.shop/images/product/minisforum-un100l-2.jpg","https://img.miniforumhub.shop/images/product/minisforum-un100l-3.jpg"],"sku":"minisforum-un100l","brand":{"@type":"Brand","name":"MINISFORUM"},"offers":{"@type":"AggregateOffer","lowPrice":59.7,"highPrice":68.7,"priceCurrency":"USD","availability":"https://schema.org/InStock","url":"https://miniforumhub.shop/products/minisforum-un100l","offerCount":2}}\n
\n\n
\n1. Brand of SSD and RAM in the UN100L
We purchase essential hardware from different brands based on the same technical specifications, including SSDs, Wi-Fi cards, RAM, HDDs, power supplies, etc. Due to the limited resources and brands of RAM and SSD, we choose Samsung, Kingston, Crucial, Adata, Phison, etc. as our RAM and SSD suppliers.
Each piece of hardware has passed a strict quality inspection and met the factory's standards before it is delivered to MINISFORUM. In addition, there is no difference in the warranty policies of these hardware suppliers.
\nThe hardware brands may vary from batch to batch. Please rest assured that they all meet MINISFORUM's standards and are all covered by the warranty.
\n2. Do you have a warranty on the UN100L?
All products purchased on MINISFORUM's official store are covered by our 2-year warranty. Learn more about our warranty policy.
3. Where do you ship to?
We offer free shipping for the majority of the world.
Available countries and regions:
United States, Saudi Arabia, Canada, Singapore, Australia, Japan, United Arab Emirates, South Korea, Malaysia, New Zealand, Hong Kong, Macau.
Learn more about our shipping policy.
\nFor customers in Europe, please place your order in our branch stores https://store.minisforum.de/ and https://store.minisforum.uk/.
\n4. What's the maximum resolution? How many monitors can be connected at the same time?
Up to three monitors can be connected at the same time with a maximum resolution of 4K.
5. Can I use the USB-C port to power up the UN100L?
The USB-C port on the UN100/UN305 can be used as a power supply port.
6. What's the spec of Wi-Fi and Bluetooth of UN100L?
Wi-Fi 5
Bluetooth 4.2
7. Does the UN100L have pre-installed Windows?
Except for the barebones version, all versions come with Windows 11 pre-installed. The barebones version does not include RAM and SSD; therefore, it does not have pre-installed Windows 11.
8. How do I install Windows OS for the barebones version?
Please click the link to our support page below to download Windows 11.
Note: MINISFORUM does not offer keys for the Windows OS.
https://www.minisforum.com/front/support
MINISFORUM UN100L
-
Meet UN100L
-
Specification
-
FAQ
On Board 16GB
New Generation LPDDR5 Memory
Supports M.2 SATA SSD, 2.5 inch Hard Drive and TF Card
Easy to use, ultra-low power consumption
Quiet and power-saving. Energy-saving and environmentally friendly
Rich interface, easy to connect
HDMI+DP+USB-C
Supports three-screen display and one cable to connect all your devices
Support AV1 video decoding
Supports 4K60Hz HD output
Compact size, does not take up space
Keeps your desktop tidy
Supports VESA mounts
Can be placed flat or wall-mounted
Package Content
MINISFORUM UN100L
UN100 Processor
Intel® N100 Processor, 4 Cores/4 Threads
(6M Cache, up to 3.4 GHz)
Graphics
Intel® UHD Graphics
Memory
LPDDR5 Single Channel (OnBoard, 4800Mhz, up to 16GB)
Storage
M.2 2280 PCIe3.0 SSD ×1(PCIe 3.0 ×1 )
Storage Expansion
TF Card Slot ×1
UFS2.1(128G/256G Optional)
2.5 inch SATA3.0 HDD Slot ×1
Wireless Connectivity
Onboard Intel® Wireless-AC 9560 (Wi-Fi 5，BlueTooth 5.1)
Video Output
HDMI ×1, DisplayPort ×1, USB-C ×1
Audio Output
HDMI ×1, DisplayPort ×1, Audio Jack ×1
Ports & Buttons
RJ45 1000M Ethernet Port×1
USB2.0 Type-A Port ×2(In Back)
USB3.2 Gen2 Type-A Port ×2(In Front)
USB3.2 Gen2 Type-C ×1(Alt Data DP and PD)
HDMI ×1
DisplayPort ×1
DMIC ×1
Audio Jack ×1
Clear CMOS ×1
Power
DC 12V (adapter included)
System
Windows 11
1. Brand of SSD and RAM in the UN100L
We purchase essential hardware from different brands based on the same technical specifications, including SSDs, Wi-Fi cards, RAM, HDDs, power supplies, etc. Due to the limited resources and brands of RAM and SSD, we choose Samsung, Kingston, Crucial, Adata, Phison, etc. as our RAM and SSD suppliers.
Each piece of hardware has passed a strict quality inspection and met the factory's standards before it is delivered to MINISFORUM. In addition, there is no difference in the warranty policies of these hardware suppliers.
The hardware brands may vary from batch to batch. Please rest assured that they all meet MINISFORUM's standards and are all covered by the warranty.
2. Do you have a warranty on the UN100L?
All products purchased on MINISFORUM's official store are covered by our 2-year warranty. Learn more about our warranty policy.
3. Where do you ship to?
We offer free shipping for the majority of the world.
Available countries and regions:
United States, Saudi Arabia, Canada, Singapore, Australia, Japan, United Arab Emirates, South Korea, Malaysia, New Zealand, Hong Kong, Macau.
Learn more about our shipping policy.
For customers in Europe, please place your order in our branch stores https://store.minisforum.de/ and https://store.minisforum.uk/.
4. What's the maximum resolution? How many monitors can be connected at the same time?
Up to three monitors can be connected at the same time with a maximum resolution of 4K.
5. Can I use the USB-C port to power up the UN100L?
The USB-C port on the UN100/UN305 can be used as a power supply port.
6. What's the spec of Wi-Fi and Bluetooth of UN100L?
Wi-Fi 5
Bluetooth 4.2
7. Does the UN100L have pre-installed Windows?
Except for the barebones version, all versions come with Windows 11 pre-installed. The barebones version does not include RAM and SSD; therefore, it does not have pre-installed Windows 11.
8. How do I install Windows OS for the barebones version?
Please click the link to our support page below to download Windows 11.
Note: MINISFORUM does not offer keys for the Windows OS.
https://www.minisforum.com/front/support
